VRP5G is an environmentally and safe WiFi signal repeater. Working in the repeater mode, VRP5G can be doubled to extend the original WiFi signal coverage, while it can ensure the security of the wireless signal, its working principle is: at the edges of the original WiFi hot spot signal coverage, put VRP5G that is in “repeater mode”, VRP5G can receive the weak WiFi signal, and then zoom into the normal, safe strength, and after optimization, error correction processing, to achieve signal coverage distance doubled extension under safe. This differs from the traditional wireless signal amplifier - only amplifies the signal and ignore the wireless security. Its main features as below:
1. Support 110-240V power supply;
2. Support both 2.4G and 5G;
3. Support 802.11ac, 802.11n WiFi transmission protocol
4. 5G WiFi transmission rate: 900Mbps,2.4G WiFi transmission rate: 300Mbps;
5. RF power : 2.4G 14.5dBm, 5G 17dBm/23dBm Adjustable;
6. The transmission distance of 5G WiFi(without obstacle) : 150m;
7. Support connecting more than 20pcs WiFi terminal at the same time;
8. Adopt the original creation D/A temperature compensated auto frequency control technology（TAFC）,make sure the lasting stability to ensure that the WiFi signal is dropped;
9. Original creation VDNS virtual domain configuration technology to solve the user’s trouble of configuration;
10. Low power consumption, the total power consumption is less than 4W;
11. Support WiFi intelligent bridge mode;
12. WiFi intelligent bridge function, Wireless switch wired, wired switch wireless, intelligent switch;
13. WiFi intelligent repeater mode, it supports WiFi hot spots scan automatically and WiFi hot spot memory function;
14. Support to disable 2.4G and 5G WiFi network;
15.Good compatibility, almost compatible with all smart phones, tablet PCs, laptops, Internet and other WiFi devices;
In the software operation, Houtian network uphold the consistent simple, user-friendly design, abandoned the verbose of IP setup for traditional wireless repeater, using the virtual domain configuration techniques(VDNS)configuration, and also support the use of IE browser configuration and PC-specific software configuration(no IP connection), on the steps, it is even more concise, no redundant operations, which greatly facilitates the use of different levels of user.
|
Hardware Spec | |
|
Protocol Standard |
IEEE 802.11ac, IEEE 802.11g, IEEE 802.11b, IEEE 802.11n technology |
|
WiFi Transmission |
2.4G 300Mbps, 5G 900Mbps |
|
Interface |
10/100M adaptive Ethernet base |
|
Button |
Reset button (long press 5s then release) |
|
LED |
Status indicator: Ethernet port status light; 2.4G WiFi indicator light; 5G WiFi indicator light; |
|
Antenna |
Built-in 2pcs Smart omnidirectional 2.4G Antennas; Built-in 2pcs intelligent omnidirectional 5G Antenna. |
|
WiFi Related | |
|
Supported band |
2.4G and 5G |
|
Basic Function |
WiFi Swtich; SSID broadcast switch; WiFi mode option: 11ac\a mixed , 11n only, 11 bgn mixed, 11 bg mixed, 11g only, 11b only; WiFi Hot spot scan automatically; WiFi Hot spot switches. |
|
Working Mode |
WiFi intelligent repeater mode; Repeater (WiFi signal repeater) mode, can extend WiFi transmission distance; WiFi intelligent bridge mode. |
|
WiFi Security |
64/128/WEP encryption; WPA-PSK/WPA2-PSK、WPA/WPA2 security mechanism |
|
System Function |
Restart device Reset factory Administrate account and password revise Firmware upgrade |
| VRP5G——Quick Setting Guide |
| VRP5G——Product Specification |
| Firmware Upgrade Guide |
| VRP5G-CE-RTTE Certificate |
| VRP5G-FCC-ID Certificate |
| VRP5G-ROHS-Certificate |
